Direct replacement for PEL 105 (2137.59), offers 5x faster operation speed
Backlit monochrome LCD screen allows for easy viewing of measurements
Includes 4x 196A-24-BK AmpFlex Sensors
Additional sensors sold separately, please see Accessories and Options tab for compatible models
4x voltage and 4x current channels with auto-recognition of connected current sensors and probes
Performs single, dual (split-phase), and 3-phase (Y, Δ) testing
Performs measurements for most DC, 50 Hz, 60 Hz, and 400 Hz distribution systems
Supports 17 types of connections or electrical distribution systems
RMS and DC measurements with 128 samples/cycle simultaneously on each phase
Captures active, reactive (N, D, Qf) and apparent power values along with active energy values
Fundamental active power values (Pf), balance active power values (P+), and unbalance active power (Punb)
Phase data includes cos (φ), tan (Φ), and power factor (PF)
Total Harmonic Distortion (THD) calculation for currents and voltages
32 alarms allow for configuration, remote alerts, and automatic reports
Recordings cover several months for long-term logging
Effortless energy logging allows for smarter power management
Wide range of applications including predictive/preventive maintenance, energy audits, cost optimization, and IT infrastructure maintenance
Ideal for users in renewable energies, process industries, build construction/renovation, public services/transport, and data center fields
Simple-to-use minimal button operation
2137.82 Pole Mounting Kit (sold separately) allows for instrument mounting
IP67 rated watertight case allows for use in field or outdoors
Expandable storage records data on SD card up to 32 GB
Able to be installed without cutting off power supply
Powered directly from phase, eliminates reliance on battery source
DataView software allows for configuration, data retrieval, real-time measurement display, data analysis, and report generation
Downloadable PEL app on Android devices provides comprehensive and instantaneous motor electrical parameters such as rotation speed, efficiency, and torque
PEL app provides users with ability to configure measurements/recordings and display data in real-time
Multiple connectivity options supports USB, Ethernet, Wi-Fi, and remote access with DataViewSync
Remote access and real-time monitoring for viewing and analyzing power consumption from anywhere
Specifications
General
Number of Voltage Channels: 4 (V1, V2, V3, Earth/Ground)
Number of Current Channels: 4 (L1, L2, L3, Earth/Ground)
Measurements
Phase-Neutral (V) Voltage Range: 10V to 1000VAC/DC
Phase-Phase (U) Voltage Range: 17V to 1700VAC
AC Current Range (Meter Only): 5 mA to 12 kAAC
AC Current Range (Meter with 196A-24-BK AmpFlex Sensors): 200 mA to 12 kAAC
DC Current Range: 50 mA to 1300ADC
Other
NEC Article 220.87 Load Study Compliant: Yes, DataView configuration button and report templates
External Power Supply: Power adapter
Safety/Mechanical
Electrical Safety (IEC 61010): 1000V CAT IV
Ingress Protection: IP67
196A-24-BK AmpFlex Sensors
Allows user to capture higher current measurements
Measures current flowing in conductor or bus bar without opening circuit
Insulates user from dangerous voltages within current
Specifications
Sensor Size: 24 in.
Maximum Conductor Size: 7.64 in. (194 mm)
Lead Length: 10 ft. (3m)
Current Range: 100A to 10000AAC
Protection: IK04, IP67, waterproof
Safety Compliance: IEC 61010-1, EN/IEC 61010-2-032, 1000V CAT III, 600V CAT IV
