BK Precision MDL4U505B

Description

• For use with MDL4U Series Mainframe and Mainframe Extension
• Populates one slot of mainframe/mainframe extension
• Compatible with MDL4U (non-B) Modules for sharing same mainframe
• Identical modules can be combined in parallel to increase maximum power for high current applications
• Ideal for testing wide range of power sources from multi-output DC power supplies to batteries, fuel cells, and photovoltaic arrays
• Capable of operating in constant voltage (CV), constant current (CC), constant resistance (CR), and constant power (CW) modes
• Designed with front and rear input terminals

Specifications

Input Rating

• Input Voltage: 0V to 600V
• Input Current (Low): 0A to 3A
• Input Current (High): 0A to 30A
• Input Power: 500W
• Channels: 1
• Minimum Operating Voltage (Low): 0.54V at 3A
• Minimum Operating Voltage (High): 5.4V at 30A

CV (Constant Voltage) Mode

• Range (Low): 0.1V to 18V
• Range (High): 0.1V to 600V

CC (Constant Current) Mode

• Range (Low): 0A to 3A
• Range (High): 0A to 30A

CR (Constant Resistance) Mode

• Range (Low): 0.2Ω to 10Ω
• Range (High): 10Ω to 7.5 kΩ

CW (Constant Power) Mode

• Range: 500W
