Fluke Calibration 1620A-H

Description

• Kit includes high-accuracy sensor, wall mount bracket, and RS-232 cable
• Calibrated temperature accuracy: ± 0.125 °C from 16 °C to 24 °C (± 0.225 °F from 60.8 °F to 75.2 °F)
• Calibrated RH accuracy: ± 1.5 % RH from 20 % RH to 70 % RH
• Expected extrapolated performance (uncertified): ± 0.5 °C (± 0.9 °F) outside calibrated range, ± 3 % RH outside calibrated range
• Delta temperature accuracy ± 0.025 °C for ± 1° changes within 15 °C to 35 °C (± 0.045 °F for ± 1° changes within 59 °F to 95 °F)
• Temperature resolution: User selectable up to 0.001 °C/°F on front-panel display (0.01° recorded)
• Delta humidity accuracy: ± 1.0 % RH for ± 5 % changes within 20 % RH to 70 % RH
• RH resolution: User selectable up to 0.01 % on front-panel display (0.1 % recorded)
• Inputs: Up to two sensors, measure temperature and relative humidity, detachable, cable-extendable, interchangeable, self-contained calibrations, may be assigned unique 16-character identifications
• Display: 240 x 128 graphics monochrome LCD, displays password-protected temperature/humidity data graphically, numerically, and statistically (one or both channels); 16 pre-defined, user-changeable screen setups
• Memory: 400,000 typical individual date/time-stamped readings
• Alarms: Password-protected visual, audible, and external alarms for temperature, temperature rate, RH, RH rate, and fault conditions
• Alarm port output: 2.5 mm two-conductor subminiature plug, 0 V normal, 11 to 12 V active, sources up to 20 mA
• Connectivity: Ethernet, RS-232, RF (optional)
• Ethernet: RJ45 jack, 10 Base-T or 100 Base-TX; static or dynamic (DHCP client) IP address assignment
• Web page: Embedded web page interface features instrument identification, measurements, password-protected terminal page; can be disabled
• Mounting: Wall mounted (hardware included) or set on bench top
• Power: 12 VDC from external 100 to 240 VDC power supply
• Battery backup: Standard 9 V battery enables continued measuring during power disruptions
