Batteries: 2 Lithium metal batteries required (included)
Operating humidity: 10% to 90%
Item Weight: 0.634 ounces
Package dimensions: 6.1 x 4.65 x 1.57 inches
Smart Logger V2 Specifications
Signal transmission frequency: 2.4 GHz
Protocol standard: BLE 5
Modulation mode: GFSK
Advertisement interval: 2 seconds
Output power: 0 dBm
Communication rate: 1 Mbps
Transmission distance: Up to 150 ft (46 meters)
Storage: 16,384 data measurements
Operating temperature range: -22°F (-30°C)~140°F (60°C)
RH measurement range: 0~100%RH
Temperature measurement accuracy: ±0.1°
RH measurement accuracy: ±1.5%RH
Material: ABS, PCB, FR4
Power source: Battery powered
Orion 950 Specifications
Scanning area: 2.0 inches (50mm) x 2.5 inches (63mm)
Weight with boot: 7.2 oz. (204g)
Power: 9-volt battery (Wagner recommends using non-rechargeable Alkaline or Lithium or rechargeable NiMH batteries)
Auto power shut-down: 60 seconds
Measurement ranges: MC for wood: 4.0% to 32.0% (range will vary slightly depending on species setting)
Relative measurement scale: 0 to 100
Dual depth measurement: Shallow scan mode reads into wood to .25 in. (6.4mm) deep; deep scan mode reads into wood to .75 in. (19mm)
Internal data storage capacity: 100 saved readings
Ambient temperature range: 32˚F to +110˚F (0˚C to +43˚C)
Ambient relative humidity range: 0% to 100%
Equilibrium moisture content measurement range: 0% to 40.7%
Dew Point Range: -85˚F to +110˚F (-65˚C to +43˚C)
Absolute humidity range: 0 to 431.1 lb/ft (0 to 61.6 kg/m)
Specific gravity range for wood species: 0.20 to 1.0 SG
Storage temperature and Humidity: +50˚F to +90˚F (+10˚C to +32˚C), Maximum relative humidity of 95%, Non-condensing
Operating temperature range: +32˚F to +110˚F (+0˚C to +43˚C)
Backlight: Includes adjustable backlit display
Infrared Thermometer Specifications
Measurement range: -25.6° F to 707° F (-32° C to 375° C)
Accuracy: ±2% of reading
Distance to spot ratio: 12:1
Emissivity: Preset at 0.95
Response time: ≤500ms
Repeatability: ±1% of reading or ± 2° F (1° C), whichever is greater
Battery: 9V
Built-in Ambient Sensors
Measures temperature and relative humidity (RH)
Smart app integration: Store, organize and send readings directly to Wagner Sentry app via Bluetooth; monitor ambient conditions effortlessly on smart devices
Data collection and storage: Capture, record and send up to 16,384 readings of ambient temperature and relative humidity (RH) data
Floor sentry compatibility: Pairing Floor Sentry and Smart Logger V2 to Wagner Sentry app allows users to view both ambient and in-floor conditions simultaneously, enabling them to easily transmit and record data, and even send reports via email
Dual depth measurements: Measure moisture at 0.25 in. or 0.75 in. depths to accommodate variety of wood thicknesses
Built-in temperature and humidity sensor: Monitor ambient conditions, ensuring optimal settings for woodworking projects
Auto-EMC calculations: Automatically calculates equilibrium moisture content (EMC), letting users know when wood is ready for installation or fabrication, eliminating guesswork
Dew point and GPP/GPK calculations: Instantly calculate environment’s dew point and grains per pound/kilogram to understand specific humidity levels
On-demand calibration: Maintain meter’s precision without hassle of returning it for recalibration
Fast, non-damaging pinless sensor: Provides non-invasive readings, measuring inside wood, not just on wood surfaces
Relative measurement mode: Measure moisture in non-wood building materials such as drywall, plywood, OSB, and MDF
Smart app integration: Store, organize and send readings directly to Wagner Sentry app via Bluetooth; monitor ambient conditions effortlessly on smart devices
Auto data collection mode: Take and store multiple readings automatically without seeing screens
Data collection and storage: Users can choose between manual or automatic data collection modes; view detailed moisture stats directly on meter for easy tracking and analysis
