Batteries: 2 Lithium metal batteries required (included)
Operating humidity: 10% to 90%
Smart Logger V2 Specifications
Signal transmission frequency: 2.4 GHz
Protocol standard: BLE 5
Modulation mode: GFSK
Advertisement interval: 2 seconds
Output power: 0 dBm
Communication rate: 1 Mbps
Transmission distance: Up to 150 ft (46 meters)
Storage: 16,384 data measurements
Operating temperature range: -22°F (-30°C)~140°F (60°C)
RH measurement range: 0~100%RH
Temperature measurement accuracy: ±0.1°
RH measurement accuracy: ±1.5%RH
Material: ABS, PCB, FR4
Power source: Battery powered
C555 Specifications
Scanning area: 2.0 inches (50mm) x 2.5 inches (63mm)
Power: 9-volt battery
Auto power shut-down: 60 seconds
Measurement ranges: Moisture range for concrete: 0.1 to 6.9
Storage temperature and humidity: +50˚F to +90˚F (+10˚C to +32˚C), Maximum relative humidity of 95%, non-condensing
Operating temperature: +32˚F to +110˚F (+0˚C to +43˚C)
Infrared Thermometer Specifications
Measurement Range: -25.6° F to 707° F (-32° C to 375° C)
Accuracy: ±2% of reading
Distance to spot ratio: 12:1
Emissivity: Preset at 0.95
Response time: ≤500ms
Repeatability: ±1% of reading or ± 2° F (1° C), whichever is greater
Battery: 9V
DataGrabber with Bluetooth Specifications
Measurement range: -25.6° F to 707° F (-32° C to 375° C)
Accuracy: ±2% of reading
Distance to spot ratio: 12:1
Emissivity: Preset at 0.95
Response time: ≤500ms
Repeatability: ±1% of reading or ± 2° F (1° C), whichever is greater
Battery: 9V
Smart Logger V2
Built-in ambient sensors: Measure temperature and relative humidity (RH)
Smart app integration: Store, organize, and send readings directly to Wagner Sentry app via Bluetooth; monitor ambient conditions effortlessly on smart device
Data collection and storage: Capture, record, and send up to 16,384 readings of ambient temperature and relative humidity (RH) data
Floor sentry compatibility: Pairing Floor Sentry and Smart Logger V2 to the Wagner Sentry app allows users to view both ambient and in-floor conditions simultaneously, enabling users to easily transmit and record data, and even send reports via email
ASTM F2659 compliance: Provide preliminary evaluation of comparative moisture conditions of concrete, gypsum cement, or other floor slabs and screeds; good tool for testing surface moisture in concrete
Built-in ambient sensors: Measure ambient temperature, relative humidity and dew point
On-demand calibration: Maintain meter’s precision without hassle of returning it for recalibration
Relative measurement mode: Measure other concrete-similar materials such as concrete blocks
Depth measurements: Measure moisture hotspots 0.5 inches into concrete slabs
Press to hold readings: Lock in moisture readings with single press of button—ideal for tight corners, overhead spaces, or hard-to-reach areas; perfect for situations where display is not visible
