Kit combines CM78-PV True-RMS Solar Clamp Meter, PV78 Solar Irradiance/Temperature Meter, PV48 Solar Photovoltaic Panel Tester/I-V Curve Tracer, TG268 Spot Infrared Thermal Camera, TA74 Universal Flex Current Probe, TA89/TA90 Solar Photovoltaic Test Lead Sets, and TA91 Rugged Carrying Pouch
Applications
Verify performance and safety of installed solar systems
Monitor and maintain large-scale solar power plants
Ensure quality of solar panels during production
Inspect electrical, mechanical, and automotive equipment
Monitor equipment for signs of degradation before it fails
Ensure energy efficiency in building inspections
Conduct process manufacturing and quality assurance checks on high-temperature applications at safe distances
CM78-PV True-RMS Solar Clamp Meter
Measures solar string DC power and performance up to 1500 kVA at CAT III 1500V rating
Safely locates and identifies overheating components with non-contact IR thermometer and laser pointer
Performs accurate measurements with TRMS readings, VFD mode, and low impedance (LoZ) mode
Supports wireless METERLiNK connectivity for quick data collection and sharing
Specifications
Voltage Range: 1000VAC, 1500VDC
VFD Range: 1000VAC
LoZ Range: 1000VAC, 1500VDC
Current Range: 1000AAC/DC
PV78 Solar Irradiance/Temperature Meter
Instantly measures solar irradiance as required by IEC 62446-1 standard
Measures solar irradiance, panel temperature, array direction, and inclination
Compact design with external temperature probe and mounting bracket for continuous measurements
Fitted with high-contrast LCD screen that is easy to read even under direct sunlight
Supports wireless METERLiNK connectivity for quick data collection and sharing
Specifications
Irradiance Range: 0W to 1400 W/m²
Inclination Angle Range: -90° to 90°
Meter Temperature Range: 14°F to 122°F
External Probe Temperature Range: -22°F to 212°F
PV48 Solar Photovoltaic Panel Tester/I-V Curve Tracer
Instantly measures maximum power, temperature, and I-V curve
Provides graphical data analysis with I-V curve up to 800W per panel
Fitted with high-contrast LCD screen that is easy to read even under direct sunlight
Specifications
Maximum Power Value (Pmax) Range: 0W to 800W
Voltage at MMPT Point (Vmax) Range: 0V to 60V
Current at MMPT Point (Imax) Range: 0A to 30A
TG268 Spot Infrared Thermal Camera
Accurately captures temperature measurements to help users diagnose issues
Spotmeter measures temperatures at center of image as indicated by laser pointer
MSX image enhancement adds additional details to aid in troubleshooting and diagnose problems faster
Super resolution upscales thermal images to 320 x 240 for improved details of thermal images
Performs timelapse image capture, trending, logging, and alarms directly on camera
Captures readings, images, and videos for analysis and sharing with FLIR METERLiNK app
Specifications
IR Resolution: 160 x 120
Super Resolution: 320 x 240
Distance/Spot Size Ratio: 24:1
Object Temperature Range: -13°F to 752°F
TA74 Universal Flex Current Probe
Allows user to easily take measurements in tight spots as compared to traditional hard jaw clamp meters
Constructed with narrow flexible coil clamp and locking mechanism
Measures multiple conductors and targets with limited clearance
Bright, dual LED worklights provide built-in illumination for dark cabinet
Specifications
Maximum AC Current: 3000A
AC Current Ranges: 30A, 300A, 3000A
Flex Coil Length: 18 in.
TA89/TA90 Solar Photovoltaic Test Lead Sets
TA89 features MC4 (male/female) to 4 mm sheathed banana plugs
TA90 features dual MC4 (both male and female) to 4 mm sheathed banana plugs
Ensures safe current and voltage measurements on PV modules and systems
Creates MC4 connection between solar panel and inverter for troubleshooting and maintenance of PV systems
TA91 Rugged Carrying Pouch
Flexible adjustable compartments for easy storage of meters of accessories
Organizes and protects work equipment and personal items
Rugged exterior material with comfortable soft mesh pocket
Attached shoulder strap for easy hands-free transport
