TREND Networks LTX5515-R-1310

Description

• Two Voltage Input Ranges
• Receives DC to 25 MHz with 0.1% Accuracy
• 12 Bit Precision Analog Data
• Four Independent Digital Channels – DC to 24 MHz Switching Rates
• Two Impedance Settings
• Receives without Conducting EMI
• Transmission of High Quality Video

Specifications:

• Analog Signal Bandwidth: DC to 25 MHz (-3 dB)
• Input Voltage Ranges: +/- 1V or +/- 5V (Selectable)
• Resolution: 12 Bits
• Transfer Accuracy: +/- 0.1% Full Scale, +/- 20 mV Offset
• Signal Latency: Approximately 300 nS (with One Meter of Fiber)
• A/D Sampling Rate: 100 Megasamples/s
• Input Impedance: 50 Ohms or 1 Megohm/20 pF (Selectable)
• Output Drive Capability: +/- 5V Open Circuit, +/- 2V into 50 Ohm Load
• Output Impedance: 50 Ohms
• Digital Inputs: TTL, LVTTL, CMOS Compatible
• Digital Outputs: LVTTL (0 – 3.3V)
• Digital Switching Rates: 0 – 24 MHz
• Digital Signal Edge Uncertainty: 0 – 10 nS
• Laser Wavelength: 1310 nm +/- 20 nm
• Optical Transmission Rate: 2.0 Gb/s
• Loss Budget: 15 dB max
• Optical Return Loss:> 15 dB
• Laser Safety Classification: Class I Safety per FDA/CDRH and IEC-825-1 Regulations
• Typical Trans. Distances: 250M – 50/125µ Fiber, 150M – 62.5/125µ Fiber
• Typical Trans. Distances (1310 nm):> 10 KM with 9/125 Micron Fiber
• Fiber Optic Connectors: ST Standard
• LED Annunciators Provided: Input Overload (TX), Optical Signal (RX)
• Power Supplies: Universal Wall Mount, US, UK, Continental Europe, Australian Plugs
• Power Requirements: 95-260VAC, 50-60 Hz, 16VA Max.
• Operating Temperature: 0° to 40°C
• Weight: 0.46 kg
