Vitrek QTI-9

Description

• 1x QT Insite Test Automation Software License Key for single compatible unit
• Compatible Hipot Tester Models: 951i, 952i, 953i, 954i, 955i, 956i, 957i, 959i
• Compatible IR Tester/Teraohmmeter Models: 981i, 983i
• Compatible Switch Unit Models: 948i, 964i
• Enables users to automatically initiate tests then collect and store results data
• Tracks test results by part number
• Shows changes in performance via lot number
• Enables barcode scanning for recalling ready-to-run test sequence of specific DUTs
• Multiple DUT numbers can be linked to single test sequence
• Able to display detailed instructions and images to operator for reduced training time
• Number of test steps only limited by attached instrument
• Records results of every test for detailed analytics
• Results database can be searched, filtered, and exported
• Filtering functions allows for individual tests to be recalled for auditing purposes
• Vastly configurable report options for each test sequence
• Results of recalled tests can be saved as .pdf/.csv formats
• Allows for automatic printing of test reports
• Operator permissions provide security over test settings
• Provides clean and intuitive means for creating or modifying up to 999 electrical safety test sequences
• Electrical safety test sequences include AC and/or DC voltage withstand, insulation resistance, and ground bond testing
• Users, system configurations, and test sequences can be programmed in remotely without specialized hardware
